PANASONIC CABINENT FAN FV-15NS3NALHM

• Low noise series
• Single phase
• Exhaust type
• Ceiling mounting
• 2-speed selectable
• Air volume = 340m3/h

• Exhaust type
• The fan shall be suitable for ceiling mounting
• Long life condenser motor with thermo cut-off
• High performance 'Twin Flow Fan' employed for powerful airflow and high static pressure
• Newly designed casing with taper scroll minimizes turbulence inside the casing
• Noise absorption material adopted for low noise operation
• Slim and compact design allow installation at narrow ceiling space
• Embedded terminal box with metal terminal cover enhances durability and safety
• Able to install upside down for different location of inspection opening

Voltage [V]



220 230 240



Frequency [Hz]



50 60

Air Volume - Hi [CMH]340

Consumption - Hi [W]33

Noise - Hi [dB(A)]25

RPM - Hi [min-1]1270

Weight [kg]6.50

See All Specs





HideAir Volume



[CFM]

200

162



[CMH]

340

275

HideConsumption [W]

33

29.50

HideNoise [dB(A)]

25

22

HideRPM [min-1]

1270

1100

HideDuct Size [mm]

Ø150

HideImpeller Diameter [cm]

128

HideWeight [kg]

6.50
