TSTY SG-M-250kva Oil Immersed Isolation Power Transformer (400-400V) - L
NGN6,850,000.00
Availability:
In stock
Out of stock
TSTY SG-M-250kva Oil Immersed Isolation Power Transformer (400-400V)
Product Description
TSTY SG-M-250kva Oil Immersed Isolation Power Transformer (400-400V)
Product Features
Model
SG-M-250kva
Rated Capacity (KVA)
250
H.V
0.4 KV
L.V
0.4 KV
Short Circuit Impedance
4%
Off load Losses
620(±15%)
On load Losses
3120(±15%)
H.V Current (A)
360.84
L.V Current (A)
360.84
Winding Material
Copper to Copper 1290*920*1020 mm
Dimension
900 kg
Weight
50HZ
Frequency Vector Group
Dyn11
Phase
3 phase
Type
Oil-immersed
Core
Mineral oil
Cooling Type
Silicon steel sheet
Oil level thermometer
ONAN
Oil level indicator
Equipped
Pressure relief device
Equipped
Warranty
Equipped
Service Lifetime
2 years
